日本PEACOCK孔雀量表

产品展示

首页 >>> 产品展示 >>> 日本PEACOCK孔雀量表 >>> 厚度计 >>> 日本PEACOCK孔雀量表 FFA-3 针盘式恒压厚度计

产品[

日本PEACOCK孔雀量表 FFA-3 针盘式恒压厚度计

]资料

点击看大图

如果您对该产品感兴趣的话,可以 sendmsg

给我留言
产品名称: 日本PEACOCK孔雀量表 FFA-3 针盘式恒压厚度计
产品型号: FFA-3
产品厂商: 深圳市鑫腾明计量仪器商行
产品报价:

产品特点

日本PEACOCK孔雀量表 FFA-3 针盘式恒压厚度计

日本PEACOCK孔雀量表 FFA-3 针盘式恒压厚度计 的详细介绍

Stand type FFA Series

1?m type ( integart part of Stand )
FFA 0.001mm Type

10?m type ( with damage prevention stopper )
FFA 0.01mm Type

Measuring material	JIS. NO	Applied Model
Shrink package film.	Z 1709	FFA-1
Polyethylene package film.	Z 1702	FFA-1
Ethylene film.	K 6783	FFA-1
Polyvinyl chloride film.	K 6732	FFA-2
Leather.	K 6550	FFA-3
Artificial leather.	K 6505	FFA-3
Sheet rubber.	K 6328	FFA-4
Vulcanized rubber / Thermoplastic rubber (Hardness 35IRHD less) Contact Point ?5mm	K 6250A	FFA-5
Vulcanized rubber / Thermoplastic rubber (Hardness 35IRHD less) Contact Point ?8mm	K 6250A	FFA-6
Vulcanized rubber / Thermoplastic rubber (Hardness 35IRHD over) Contact Point ?5mm	K 6250A	FFA-7
Vulcanized rubber / Thermoplastic rubber (Hardness 35IRHD over) Contact Point ?8mm	K 6250A	FFA-8
Urethane form.	K 6402	FFA-9
Common fabric (basic).	L 1096	FFA-10
Adhesive interlined cloth (common weave).	L 1086	FFA-10
Common fabric (fuzzy material).	L 1096	FFA-11
Adhesive interlined cloth (common knit).	L 1086	FFA-11
Stockinet (common knit).	L 1018	FFA-11
Unwoven / interlined cloth (non-standard).	L 1085	FFA-12
Adhesive interlined cloth (non-woven).	L 1086	FFA-12
Tensile properties of plastics.	K 7113	FFA-13
FFA-8

Specifications Stand type FFA Series

Model

Graduation
(mm)

Range
(mm)

Indicator error
(?m)

Throat depth
(mm)

Contact Point dia
(?mm)

Anvil dia
(?mm)

Measuring force
N(gf)

Parallelism
(?m)

FFA-1

0.001

±8

1.25±0.15
( 125±15 )

FFA-2

0.001

±8

less than 0.8
( less than 80 )

FFA-3

0.01

±20

3.93±0.1
( 393±10 )

FFA-4

0.01

±20

less than 0.8
( less than 80 )

FFA-5

0.01

±20

5
( 19.625mm? )

0.2±0.04
( 20±4 )

FFA-6

0.01

±20

8
( 50.24mm? )

0.51±0.1
( 51±10 )

FFA-7

0.01

±20

5
( 19.625mm? )

0.44±0.1
( 44±10 )

FFA-8

0.01

±20

8
( 50.24mm? )

1.13±0.26
( 113±26)

FFA-9

0.01

±20

35.7
( 10cm? )

less than 0.37
( less than 37 )

FFA-10

0.01

±20

11.3
( 1cm? )

less than 2.4
( less than 240 )

FFA-11

0.01

±20

25.2
( 5cm? )

less than 0.35
( less than 35 )

FFA-12

0.01

±20

16
( 2cm? )

less than 0.4
( less than 40 )

FFA-13

0.01

±20

10
( 78.5mm? )

less than 1.57
( less than 157 )

Notification for made to order

Each material requires different measuring force,contact point diameter and unit size for JIS compliance.
Please list the approximate specifications according to your individual measuring requirements.
